Información del producto

• Continuous Drain Current Id: 49A
• Drain Source Voltage Vds: 55V
• MSL: -
• No. of Pins: 3
• On Resistance Rds(on): 0.0175ohm
• Operating Temperature Max: 175°C
• Operating Temperature Min: -55°C
• Power Dissipation Pd: 83W
• Rds(on) Test Voltage Vgs: 10V
• SVHC: No SVHC (17-Dec-2014)
• Threshold Voltage Vgs Typ: 2.1V
• Transistor Case Style: TO-220AB
• Transistor Polarity: N Channel
